MOD MC PREMIUM PM
B
0,5
To carry on a ne tuning it’s only needed to loose the two To carry on a ne tuning it’s only needed to loose the two
indicated screws without fully remove it. The clutch base hole, indicated screws without fully remove it. The clutch base hole,
grants to move ± 25 mm.grants to move ± 25 mm.
A
2.2 ASSEMBLY INSTRUCTIONS
2
2.2.8.2 CDL / CLUTCH ADJUSTMENT
2.2.8.2.3
To adjust the retainer from the second interface element proceed as shown in the details. It is only necessary to
perform this regulation if the retainer does not actuate correctly.
AIM
Clutch / CDL base
hidden for ease
the explanation,
do not remove it
Only when a change in the support hole position is required, do Only when a change in the support hole position is required, do
you need to fully remove the screws.you need to fully remove the screws.
Loosen both screws shown in the image to perform ne tuning. Loosen both screws shown in the image to perform ne tuning.
It is not necessary to fully loosen.It is not necessary to fully loosen.
