-45-
Cables and Requirments
The maximum distance of the wiring is limited in the DT system. Using different cables may also
affect the maximum distance which the system can reach.
Cable and distance(unit:m)
Cable Usage A B
≤2 IM
B
≤16 IM
Twisted cable 2x0.75mm
2
60 100 40
Twisted cable 2x1mm
2
80 120 60
A
B
FVI-6017PC6
Basic IN-OUT Wiring Mode
