Parameter Description/setting options
System parameter (CPX-E)
Filter alarm U
off
/U
ven
SCS monitoring
SCO monitoring
Undervoltage monitoring U
off
Undervoltage monitoring U
ven
SCV monitoring
You can find detailed information in the "Descrip-
tion of the automation system CPX-E"
è 1.1 Applicable documents.
– SCS = Short circuit/overload in sensor sup-
ply
– SCO = Short circuit/overload at outputs
– SCV = Short circuit/overload at the valves
Analogue process data format Intel/Motorola
Diagnostic memory parameters (trace parameters)
Entries saved retentively with Power On
Run/stop filter 1
Run/stop filter 2
Error end filter
Error number filter
Module/channel filter
Module number
Channel number
Error number
You can find detailed information in the "Descrip-
tion of the automation system CPX-E"
è 1.1 Applicable documents.
System bus parameters (CPX-E)
Synchronisation Synchronisation with cycle time of CODESYS
application (MainTask)
Detailed information can be found in the "Online
help" è 1.1 Applicable documents.
Tab. 26 Parameter
Detailed information on parameterisation can be found in the online help for CODESYS V3.
• Observe the notes on installing CODESYS V3 in the "Instruction manual for the automation system
CPX-E" è 1.1 Applicable documents.
Parameterisation
