1. Installation
1-8
Festo P.BE-CTEU-EC-OP+MAINT-EN en 1208NH
Note
Use cover caps to seal unused co nnections. In this way you
can attain IP65 protection.
Mounting the bus node
Information on mounting the bus node on the electrical con-
nection box CAPC-... can be found in the assembly instruc-
tions supplied with the connection box.
For H-rail mounting, you will also need mounting kit CAFM-...
(CAPC and CAFM).
For mounting the bus node , a valve terminal from Festo, or
electrical connection box type CAPC-... with I-port interface, is
required.
1. Inspect the seals and sealing surfaces on the bus node
and valve terminal.
2. Push the bus node onto the valve terminal in the correct
position with no tilt.
3. First, lightly screw in the three self-tapping screws with a
TORX screw driver (size T10): use existing threads, if ap-
plicable.
4. Tighten the screws to 1.0 Nm.
