2.2.3 Replacing the I- port device – different de vice type (replacement)
Procedure in auto mode
1. Switch off the bus node power supply.
2. Remove the bus node from the I-port device
(Dismantling/Mounting:  section 1.3).
3. Mount the bus node on the new I-port device
(Dismantling/Mounting:  section 1.3).
4. Switch the bus node power supply on again.
5. Configure and parameterise the new I-port device
Procedure in tool change mode
1. Do not switch off the bus node power supply.
2. Remove the bus node from the I-port device
(Dismantling/Mounting:  section 1.3).
3. Mount the bus node on the new I-port device
(Dismantling/Mounting:  section 1.3).
The bus node detects the connected I-port device. If the
image tabl e exceeds the currently defined I/O data
length, the excess bytes will be excluded.
Notesontoolchangemode section 2.1.3
