2. Commissioning
2-17
Festo P.BE-CTEU-EC-OP+MAINT-EN en 1208NH
Port disabled
TheI-portisdeactivatedandcannotbeused.Theremustbe
no device active at this I-port. If a device is, however, active in
auto mode at startup, all other I-ports wil l also cease to be
usable because the I/O mapping will no longer be consistent.
Auto mode
Tool change mode
If a device was detected at the I-por t at startup,
a “device wrongly connected” message is gener-
ated. All other I-ports are then likewise inactive
and can no longer be used.
This error can only be reset by eliminating the
cause of the error and subsequently restarting
the system.
If this parameter is set at any time without a
device having been connected to the I-por t at
startup, a “device wrongly connected” message
will be generated for th e respective port on a
temporary basis only. All other ports can contin-
ue to be used.
If the device is disconnected again from the re-
spective I-port, this configuration error is auto-
matically reset.
When a device is detected at an I-por t for which
this parameter has been set, a “device wrongly
connected” message will be temporarily output.
All other I-ports will remain active and usable.
If the respective device is disconnected again,
the diagnostic message is automatically reset.
