A. Technical appendix
A-10
Festo P.BE-CTEU-EC-OP+MAINT-EN en 1208NH
Index AccessExplanation/noteValuesTypeDescriptionSub-
index
0x10F3 0 Diagnosis history RO
1 Maximum messages U8 20 RO
2 Newest message U8 RO
3 Newest
acknowledged
message
U8 RW
4 New message
available
BOOL RO P
5 Flags U16 0x0000 RW
6…26 Subindex 006 … 026 BYTE[2
3]
RO
0x1100 0 EtherCAT address U16 RO
0x1110 0 Virtual MAC address U8 RO
0x1111 0 Virtual IP address U8 5 RO
1 IP-address U32 RO
2 Subnet ma sk U32 RO
3 Default gateway U32 RO
4 DNS server U32 RO
5 DNS name String RO
0x1C000x1C00 0 Sync manager type U16 4 RO
1 Mailbox write U8 0x01 RO
2 Mailbox read U8 0x02 RO
3 Process output data U8 0x03 RO
4 Process input data U8 0x04 RO
0x1C32 SM 2 parameter
0x1C33 SM 3 parameter
