For Fig.12 (only DGP−... as cylinder):
1. Remove the screws.
2. Remove the pins (only with DGP−50/63).
Place a block for counterholding on the opposite side (dimension x).
j 8 12 18 25 32 40 50 63 80
X 6.25 8.5 11 13 17.5 21.5 33 41 47
Fig.13
3. Pull up the slide insert (12) (H = mounting aid).
4. Press the band system down (with a soft object).
5. Pull off the adapter part (13).
6. Push the bolt (B) through the holes.
7. Fit the slide insert (12) again with screws (and if necessary with pins).
8. Push the sliding blocks (G) onto the ends of the bolts.
9. Push the driver type F KP−... onto the
sliding blocks.
