Festo MPA Series - Dismantling the MPA-S valve terminal

5. Maintenance and conversion
5−5
Festo P.BE−MPA−EN en 0910d
5.2 Dismantling the MPA−S valve terminal
Providing the MPA−S valve terminal is easily accessible,
itneed not be dismantled when the following components are
replaced or removed:
 Valves or blanking plates
 Electronics module
 Exhaust plates or flat plate silencer
Disconnecting the electrical connections
Conne cti o n variants Procedure
CPX terminal · Instructions on disconnecting the electrical connections can be
found in the CPX system description.
Multi−pin plug connection · Loosen the fastenin g screws and remo ve the Sub−D multi−pin plug.
Tab.5/1: Disconnecting the electrical connections
Disconnecting the pneumatic connections
Disconnecting the pneumatic connections is described in
Chapter 3.
Dismantling the MPA−S valve terminal
The procedure for dismantling the MPA−S valve terminal is
described in chapter 2.
