2.2 Mounting variants
You can mount the MPA−S valve terminal in one of two ways:
Mounting method
Description
H−rail mounting The MPA−S valve terminal is suitable for
fitting onto a hat rail (support rail as per
EN 60715). There is a guide groove on the
back for hanging the valve terminal onto
the H−rail.
Wall mounting The multiple connector plate or the
pneumatic interface and the end plates
contain holes for wall mounting.
WithMPA−S valve terminals which are
longer than 280 mm, additional fastening
brackets on the supply plate are necessary
(see instructions on vibration and shock in
Appendix A, Tab.A/2).
Tab.2/1: Mounting methods of the MPA−S valve terminal
Note
Mount the MPA−S valve terminal so that there is sufficient
space for heat dissipation and ensure that the maximum
limits for temperatures are observed (see Technical data).
