2. Fitting
2−14
Festo P.BE−MPA−EN en 0910d
2.3 Mounting/removing the inscription label holder
An inscription label holder can be mounted onto each
sub−base to enable the valves or work connections to be
distinguished.
Mounting Proceed as follows:
· Clip the inscription label holders into the grooves in the
sub−bases (see diagram):
1 Fixture for the
inscription label
holder on the
sub−base
2 Inscription label
holder
1
2
Fig.2/4: Mounting the inscription label holder
