Festo MPA Series - Adding a Proportional Pressure Regulator

5. Maintenance and conversion
5−42
Festo P.BE−MPA−EN en 0910d
5.4.6 Adding a proportional pressure regulator
Necessary components
For extension you will require:
Components
Type
Proportional−pressure regulator VPPM−6TA−L−1−F−0L...
Electronics module
Sub−base
Interlinking board
also a seal without channel separation or a separating seal with
channel separation
VMPA−FB−EMG−P1
VMPA−FB−AP−P1
MPA
see Tab.1/8
Tab.5/13: Components of the proportional pressure regulator
Dismounting Proceed as follows:
1. Loosen the electric and pneumatic connections and
remove the MPA−S valve terminal from its fastening
surface (see Chapter 5.2).
2. Dismantle the sub−base or supply plate at the point
whereyou wish to extend the terminal
(seesection5.3.6under Dismantling).
Mounting Proceed as follows:
1. Do as described in section 5.3.6, under
Mountingpoints1... 3.
2. Mount the proportional pressure regulator as described
in the mounting instructions VMPA−6TA−...
3. Mount the M PA−S valve terminal onto the fastening
surface (see chapter 2 Mounting onto a wall" or
Mounting onto an H−rail").
4. Then install the pneumatic and electrical connections
(seechapter 3 Installation, connecting the MPA−S
valveterminal").
