The following product−specific terms and abbreviations are
used in this description:
Term/abbreviation
Meaning
Basic components Component (pneumatic interface, multiple connector plate, pneumatic
sub−base or pneumatic supply plate) on which further components
(exhaust plates, flat plate silencers, pressure regulators, valves or
blanking plates) are fitted.
Blanking plate Plate without valve function for sealing unused valve positions on
manifold blocks.
Components Common term for pneumatic interface, multiple connector plate,
exhaust plate, flat plate silencer, pneumatic sub−base or pneumatic
supply plate, electric supply plate, pressure sensor plate, proportional
pressure regulator, end plate, pressure regulator plate, valve and
blanking plate.
CPX modules Common term for the various modules which can be incorporated into
a CPX terminal
CPX Terminal Modular electric terminal type 50 or type 53
Electrical interface Common term for pneumatic interface, CPI interface, multiple
connector plate and AS interface.
Electrical supply plate Plate for additional supply of the valves with load voltage.
Electronics module Module in the sub−base with an LED and solenoid coil management
End plate Extreme right−hand plate of the MPA−S valve terminal and extreme
left−hand plate of the CPX terminal with holes for mounting onto a wall
Exhaust plate Plate for ducted exhaust with connection (3/5)
I/O Input/output modules
MO Manual override facility
MPA1 or MPA2 Size of the valves: MPA1 = 10 mm, MPA2 = 20 mm.
MPA−S valve terminal Modular Performance Sub−base Size−optimized valve terminal
(type32) with multi−pin plug connection, AS interface, CPX terminal or
CPI interface.
