1. Summary of components
1−16
Festo P.BE−MPA−EN en 0910d
setpoint/actual values, the valve regulates until the output
pressure has reached the setpoint value.
For constant pressure supply, which is necessary for accurate
control quality, the proportional pressure regulator has an
additional supply connection.
Configure the proportional pressure regulator via the PLC or
the Festo Handheld (CPX−MMI).
Mounting of the proportional pressure regulator is described
in the mounting instructions VPPM−6TA−...
Information on parameterising the proportional−pressure
regulator is provided in the MPA−... electronics description.
Identification of the
proportional pressure
regulator
The proportional pressure regulators on the MPA−S valve
terminal are marked by identification codes. With this
identification you can ascertain the type of proportional
pressure regulator.
ID code
Proportional pressure regulator, normally closed ...
2 % accuracy:
QA 0 ... 2 bar output pressure
QB 0 ... 6 bar output pressure
QC 0 ... 10 bar output pressure
1 % accuracy:
QD 0 ... 2 bar output pressure,
QE 0 ... 6 bar output pressure
QF 0 ... 10 bar output pressure
Tab.1/6: Identification code of the proportional pressure regulator
