2. Fitting
2−17
Festo P.BE−MPA−EN en 0910d
Note
The manual override cover caps serve for limiting the
function of the manual override and are constructed so
that they can only be removed with a great deal of
strength. During dismantling the snap hooks of the cover
will be damaged.
Dismounting Proceed as follows:
· Use a suitable screwdriver to lift the manual override caps
out of the manual overrides (see fig.):
Fig.2/7: Dismounting the manual override cover caps
