Twinflex V3 Control Panel Engineering and Commissioning Manual
20
General Operation
Introduction
This section describes the operation of the panel in response to fire and fault conditions, operator actions
required to process alarms and restore the panel to the normal state, and engineering functions such as
testing and system configuration.
The panel controls and indicators are largely the same for the 2/4 and the 8 zone panels, but there are a
few differences. Eg, the 8 zone panel uses a key switch for Access Level 2 (User) entry, whereas the 2/4
zone panels use a code entry.
Access Levels
The system access levels are set into three access levels as follows. For simple indication the status of the
‘Controls Enabled’ LED will show the level selected as follows;
Access
Level
Description Controls Enabled LED 2/4z Panel
Codes
8z Panel Codes
1 Normal OFF - -
2 User ON ACCESS 514 Key Switch
3 Engineer FLASHING ACCESS 5244 ACCESS 5244
