Twinflex V3 Control Panel Engineering and Commissioning Manual
45
Technical Data
Control Panel Specification
2/4 Zone Panel 8 Zone Panel
Dimensions (mm) 310W x 243H x 85D 315W x 400H x 90D
Weight (excluding batteries) 2.3 kg 6.2 kg
Construction V2 rated ABS Mild Steel
Cable Entry 10 x 20mm knockouts in metal
insert
15 x 20mm knockouts in top
11 x 20mm knockouts in back
Cable Type 2 core 1.5mm
2
screened fire rated cable, 500m (max per zone)
Detection Zones 2 or 4 8
Devices per Zone 32
Device Protocol Twinflex v3
Monitored Sounder Circuits 1
Monitored Relay Circuits 1
Relays on board Common fire and common fault
Operating Temperature 5
O
C to 40
O
C
Control Panel Ratings
2/4 Zone Panel 8 Zone Panel
Mains Voltage 230V AC +10% -15%
PSU Output (4 hour continuous) 900 mA 3A
Operating Voltage Nominal 24V DC
(Range 21V-35V DC)
Nominal 24V DC
(Range 21-27V DC)
Battery Charger Output 110 mA 550 mA
Charger High Impedance Voltage <4V DC
Battery Voltage 27.6 V DC @ 20
O
C
Battery Capacity (24hr standby) 2 x 12V 2.1 Ah 2 x 12V 3.2Ah (or 3.3Ah)
Battery Capacity (72hr standby) 2 x 12V 2.1 Ah 2 x 12V 7.2Ah
Zone Output (max) 250 mA 250 mA
Zone Voltage (nominal) 30V DC 27V DC
Sounder Output Load (max, fused) 500 mA 1A
Sounder Output EOL 4k7
Remote Fire Output Load (mon
relay)
250 mA 1A
Remote Fire Output EOL (mon
relay)
4k7
Auxiliary 24V DC Supply (max) 250 mA 1A
Aux DC Output Voltage 21 – 32V DC Unregulated (with panel powered from 230V AC)
NOTE: As this is unregulated, the output voltage could be higher if the
mains input voltage is increased
Repeater Outputs 50 mA sink (do not exceed a total of 280 mA)
Common Fire Relay Volt free SPCO contacts 1A 30V max
Common Fault Relay Volt free SPCO contacts 1A 30V max
Loading 27 SLU max per zone
Note: Refer to the relevant sections in the manual for full details of input and output ratings
Control Panel Fuses
2/4 Zone Panel 8 Zone Panel
Zone Output 300 mA trip polyfuse 300 mA trip polyfuse
Sounder Output 500 mA F 20mm 1A F 20mm
Remote Fire Output (mon relay) 300 mA trip polyfuse 1A F 20mm
Auxiliary 24V DC Supply 300 mA trip polyfuse 1A trip polyfuse
Mains T315 mA (Time delayed) 20mm 3AT (anti surge) 20mm
Battery 110 mA current limiter 550 mA current limiter
Battery (reverse polarity) 3.15A F 20mm (in line with leads) 3.15A F 20mm (on board)
