Fimap FIMOP - SYMBOLS USED IN THE MANUAL; SYMBOLS USED ON THE APPLIANCE

2
Protective gloves symbol:
Always wear protective gloves, to avoid the risk of serious injury to your hands.
Warning symbol:
Carefully read the sections marked with this symbol and observe the indications, for the safety of the operator and the appliance.
Covered place symbol:
The operations preceded by this symbol must always be carried out in a dry, covered area.
Symbol for squeegee movement to “work position”:
Indicates the rotation direction of the squeegee control knob in order to bring the squeegee rubbers into contact with the oor.
Open book symbol with an "i":
Indicates the need to consult the instruction manual.
Main switch symbol:
Located on the rear part of the appliance, to indicate the main switch.
Recycling symbol:
Informs the operator that the operations must be carried out in accordance with the environmental regulations in force in the place
where the appliance is being used.
Tank drainage symbol:
Informs the operator that the recovery tank must be emptied every time the solution tank is lled.
Recycling symbol:
Carefully read the sections marked with this symbol in order to ll the solution tank correctly.
Tool symbol:
Indicates the need to use tools not included in the supply.
Lifting point symbol:
Indicates the location of the elements for lifting the appliance or moving mobile appliance parts.
“OPEN” symbol:
Located on the upper part of the appliance, to indicate the position of the handle for opening the front carter.
Explosion risk symbol:
Indicates that the battery may explode in certain conditions, if not handled in accordance with the directives indicated in the
manufacturer's manual.
SYMBOLS USED IN THE MANUAL
SYMBOLS USED ON THE APPLIANCE
The descriptions contained in this document are not binding. The company therefore reserves the right to make any modications at any time
to elements, details, or accessory supply, as considered necessary for reasons of improvement or manufacturing/commercial requirements.
The reproduction, even partial, of the text and drawings contained in this document is prohibited by law.
The company reserves the right to make any technical and/or supply modications. The images are shown as a reference only, and
are not binding as to the actual design and/or equipment.
Open book symbol:
Tells the operator to read the manual before using the appliance.
Solenoid valve switch symbol:
Located on the rear part of the appliance, to indicate the solenoid valve switch.
Disposal symbol:
Carefully read the sections marked with this symbol for disposing of the appliance.
Symbol for squeegee movement to “idle position”:
Indicates the rotation direction of the squeegee control knob in order to raise the squeegee rubbers off the oor.
