14 • User Guide
2.3 Connectable Parts and Devices
Part Connection Requirements
PC HDMI connection to display Must be equipped with a power
source conforming to IEC
60601-1 or IEC 60950 stand-
ard
PC VGA connection to Display Must be equipped with a power
source conforming to IEC
60601-1 or IEC 60950 stand-
ard
External simple devices, for
instance electrical door lock,
external suction motor, etc.
Relay Max. 25 V AC / 60 V DC,
5 A
2.4 Instrument Bridge
Warning!
Beware of damaging the instrument bridge arms when lifting the backrest of the
chair.
The Instrument bridge is used to hold the instruments so that they are conveniently avail-
able for use when needed.
Instrument Bridge
Swivel arms guide the instrument hoses, so that they are located ergonomically. The in-
struments are easily reachable and in correct position ready for working. An instrument
