Fimet F1 - 2.5.2 Curing Light and Laser; 2.5.3 Ultrasonic Scaler

18 • User Guide
Rotation speed range control
Remote foot control buttons
The direction of rotation and the speed are controlled by the foot control lever (1 and 2).
2.5.2 Curing Light and Laser
Warning!
To avoid risk of eye damage, the patient must not look straight at the curing light or
laser beam.
Please read the operation instructions in the manufacturer’s manual.
2.5.3 Ultrasonic Scaler
Warning!
Check that the scaler gets water for cooling the tip. The scaler may be damaged if
not cooled properly.
The ultrasonic scaler power is controlled with a rotating knob on the back of the instru-
ment bridge. Power setting 1 is the smallest, 10 is the maximum. For more information,
see the instruction manual provided by the scaler manufacturer.
1
3
2
4
5
