2.5 Instruments and Hoses
Note!
Instruments are always manufactured by a third party. Please refer to their instructions for
their correct use and maintenance.
Warning!
To avoid risk of eye damage, do not look straight at the curing light.
Warning!
Check the locking of the instrument drill bit mechanism after replacing the drill bit.
There are five places for instruments on the instrument bridge. The arrangement of the in-
struments is set according to the customer’s order. Changing the arrangement must be
done by maintenance personnel.
Instruments that can be connected are:
 Micro motor
 Air motor
 Scaler, electric or pneumatic
 Turbine
 Syringe
 Curing light
 Special instruments, e.g. sandblasters
There are three places for instruments and suctions on the suction head. The suction
head usually has two suction hoses with suction tips.
The instruments are ready for use when picked up from their resting place. The display of
the instrument bridge shows information specific to the selected instrument; for example
rotational speed.
The instrument is controlled with the remote Foot Control. Turning the lever adjusts the ro-
tational speed of the instrument to the desired direction or activates the scaler.
2.5.1 Micro Motors
The speed scale of rotation can be changed by pressing the button 5 on the remote Foot
Control. By default, the speed range is high (H), and can be changed to medium (M) and
to low (L) by pressing the button.
