LUBRICATION AND FLUIDS CHART
Ref. No. Location Lubricant Frequency Number
1 Conveyor Bearings (Idle & Drive) CL Weekly 4
2 Feed Roll Bearings (Idle & Drive) CL Weekly 2
3 Blower Bearings CL Weekly 2
4 Rotary Air Valve Bearing CL Daily 3
5 Wheel Bearings CL Annually 4
6 Check Oil Level-Blower BO Daily 1
Change Oil-Blower BO Annually 1
7 Check Fuel Level DF Daily 1
8 Check Hydraulic Oil Level HO Daily 1
Change Hydraulic Oil & Filter HO Seasonally 1
9 Change Engine Oil & Filter MO See Engine Manual 1
10 Check Engine Oil Level MO Daily 1
11 Change Engine Coolant AF Seasonally 1
12 Check Coolant Level AF Daily 2
13 Check Air Cleaner-Engine Daily 1
14 Check Air Cleaner-Blower Daily 1
15 Rotary Air Valve Gear Box GO Seasonally 1
LUBRICANT OR FLUID USED
CL Chassis Lubricant
BO Blower Oil
[if ambient operating range is from 32° F to 90° F, use ISO Grade 100 Extreme Pressure
Gear Oil; if ambient operating range is above 90° F, use ISO Grade 150 Extreme
Pressure Gear Oil]
MO Motor Oil, 15W - 40
AF 50/50 Anti-Freeze and Water
DF Diesel Fuel
HO Hydraulic Oil
[Finn Vulhydra hydraulic oil or the closest ISO equivalent (see Hydraulic System section)]
GO 90 W Gear Oil
FLUID CAPACITIES
Fuel 11 Gallons (42 L)
Hydraulic Oil 15 Gallons (57 L)
Engine Coolant See engine manual
Engine Oil See engine manual
Gear Box Oil 9 ounces (0.26L)
TIME KEY
Daily (8 Hours)
Weekly (40 Hours)
Seasonally (500 Hours)
Annually (1000 Hours)
See Engine Manual
