BB302 MU2018 Rev B
79
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
HOSE REEL ASSEMBLY
Ref. No. Part Number Description No. Req’d
1 055714 Hose Reel Drum 1
2 055725 Drum Brake 1
3 F302-0004-03 Brake Arm 1
4 WL1504 Dust Cap 1
5 WLSN-750 Spindle Nut 1
6 WLSW-751 Spindle Washer 1
7 WLLM11949 Outer Cone 1
8 WLH-15-450E Hub Assembly 1
9 WLLM67048 Inner Cone 1
10 WLSL-150 Seal 1
11 F302-0008 Hose Reel Bracket 1
12 055713 Hose Reel Mount 1
13 055715-01 Hose Reel Lock 1
14 WLSCP-100 Cotter Pin 1
NOT SHOWN
055715-02 Hose Filter Guard Bar 1
WL25-53 Wheel Stud 4
WL6-80 Lug Nuts 4
To Next Page
