BB302 MU2018 Rev B
67
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
HYDRAULIC PARTS
Ref. No. Part Number Description No. Req’d
1 011466 Hyd Suction Strainer S-15-60 1
2 160484 Nipple 1 X 3 LG SCH 40 1
3 160010 Elbow 90 Deg 1 1
4 160498 Nipple 1 X 7 LG SCH 40 1
5 021559 1 in. Ball Valve 1
6 FW71452 1 in. MNPT X #16 MJIC 90° Elbow 1
7 055837-01 1 in. Suction Hose X 60 in. OAL 1
8 FW75113 #12 MSAE X #16 MJIC 90° Elbow 1
9 005889 Hydraulic Gear Pump 1
10 023621 #10 MSAE X #8 MJIC 90° Elbow 1
11 055837-02 1/2 in. Pressure Hose X 45 in. OAL 1
12 012086 #10 MSAE X #8 MJIC Straight Fitting 1
13 055848 Manifold, Flow Divider 1
055848-01 Manifold, Flow Divider Block 1
055848-02 Flow Divider Cartridge 1
14 055869 #8 MSAE X #4 MJIC Straight Fitting 1
15 055837-08 1/4 in. Pressure Hose X 61 in. OAL 1
16 055837-03 3/8 in. Pressure Hose X 25 in. OAL 1
17 FW71786 #8 MSAE X #6 MJIC 90° Elbow 1
18 055274 #4 MSAE X #4 MJIC 90° Elbow 2
19 012044 5000 PSI Pressure Gauge 2
20 055856 Manifold, Floor Hydraulic 1
A 055856-01 Machined Floor Manifold Block 1
B 055859 Relief Valve 1
C 055862 Porportional Flow Control (PFC) Valve 1
055856-02 PFC Solenoid Coil Nut 1
D 055863 Solenoid Coil for PFC Valve 1
E 055860 Floor ON / OFF Valve 1
055856-03 Floor ON / OFF Solenoid Coil Nut 1
F 055861 Solenoid Coil for Floor ON / OFF Valve 1
21 055837-07 1/4 in. Working Hose X 26 in. OAL 1
22 FW71909 #4 FJIC Swivel X #4 MJIC 90° Elbow 1
23 055308 #4 MSAE X #4 MJIC Straight Fitting 1
24 055602 #4 MSAE X #6 MJIC Straight Fitting 1
25 FW71636 #6 FJIC Swivel X #6 MJIC 90° Elbow 1
Continued to next page.
