BB302 MU2018 Rev B
55
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
WHEEL/AXLE ASSEMBLY
Ref. No. Part Number Description No. Req’d
1 055789 #3000 Rubber Torsion Axle 2
2 055737 Wheel / Tire Assembly (Not Shown) 2 per axle
3 005811-01 Rubber Plug Insert 1 per side
4 005812-02 Grease Cap 1 per side
5 055789-20 Spindle Nut 1 per side
6 005814-01 Cotter Pin 1 per side
7 005815-01 Spindle Nut Washer 1 per side
8 005816-02 Outer Bearing Cone 1 per side
9 005817-02 Outer Bearing Race 1 per side
10 005825-02 Wheel Lug Nut 5 per side
11 005818-02 Wheel Stud 5 per side
12 005819-02 Hub / Brake Drum Assembly 1 per side
13 005820-02 Inner Bearing Race 1 per side
14 005821-02 Inner Bearing Cone 1 per side
15 005822-02 Grease Seal 1 per side
16 005823-02 Brake Assembly, Left Side 1 per axle
005824-02 Brake Assembly, Right Side 1 per axle
17 -------------- Hex Nut (included with part number 16) 4 per side
