BB302 MU2018 Rev B
61
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
FEEDER PARTS
Ref. No. Part Number Description No. Req’d
1 055817 Conveyor Weldment 1
2 055532-01 Feeder Top Cover 1
3 055631-01 Top Cover Hinge 1
4 055532-02 Feeder Door (Center Panel) 1
5 055631-02 Feeder Door Hinge 1
6 055532-03 Feeder Door (Bottom Panel) 1
7 055586 Feeder Door Handle 1
8 085152 Feeder Door Stop 1
9 055625 Feed Roll 1
10 055563-01 Feed Roll Closure Plate 2
11 055698 Feed Roll Hydraulic Motor 1
12 055267-01 Hydraulic Motor Mounting Plate 1
004630 Torque Arrester Insert 1
13 055537 Coupling Guard 1
14 055545 Feed Roll Coupling 1
190123-32 1/4 in. Square x 2 in. Long Key 1
15 021440 Feeder Roll Bushing 1
190123-32 1/4 in. Square x 2 in. Long Key 1
16 055502 1-1/4 in. Shaft Bearing 4
17 055596-03 Feed Roll Shaft 1
18 055544 Drive Sprocket 1
190122-12 3/16 in. Square x 3/4 in. Long Key 1
19 055486 Idle Sprocket Tensioner 1
055572-06 Conveyor Spacer 1
055543 Tensioner Sprocket 1
055485 Shoulder Stud 1
20 055547 Driven Sprocket 1
190123-32 1/4 in. Square x 2 in. Long Key 1
21 055546 Roller Chain 1
22 055596-02 Conveyor Floor Drive Shaft 1
23 031258 Feeder Door Lock Lever 2
---------- 3/8-16 X 2 in. Long Square Head Screw 2
---------- 3/8-16 Hex Nut 2
24 052436 Safety Switch 2
25 055528 Chain Cover 1
26 055745 Clamping Strap 1
27 055744 Closure Flap 1
To Next Page
