BB302 MU2018 Rev B
53
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
TRAILER COMPONENTS
Ref. No. Part Number Description No. Req’d
1 055871 Fuel Tank Assembly 1
055871-01 Fuel Tank 1
031464-02 Drain Cock 1
031464-03 Grommet 3
031464-04 Fuel Tube Assembly 2
031459 Fuel Level Gauge 1
005726 Fuel Tank Cap 1
2 A1487-001 Toolbox (Modified) 1
3 A1096-001 Manual Canister 1
4 055737 Tire and Rim Assembly 4
055789 Axle with Brake Assembly (see Wheel / Axle Assembly) 2
5 022588 Trailer Jack 1
6 055527 Engine and Blower Canopy 1
7 055846 Front Canopy Support 1
8 055845 Rear Canopy Support 1
9 055821 Front Canopy Cover 1
10 055847 Battery Box tray 1
11 080223 Battery Box 1
12 002256-12 Battery 1
13 F90-0016 Battery Box Hold-down 1
14 055844 Control Box Mounting Plate 1
15 055875 Control Box Cover Frame 1
16 055876 Control Box Cover Plexiglass 1
17 055669 Snap Hinge 2
18 055858 Muffler Guard 1
19 055715-02 Guard Bar 1
20 A1220-001 License Plate Light 1
21 004720 License Plate Bracket 1
22 A1228-001 Taillight - Left-Hand Side 1
23 A1259-001 Taillight - Right-Hand Side 1
24 A1227-001 Amber Clearance / Marker Light 2
25 A1304-001 Amber Reflector, Rectanglar 2
NOT SHOWN
085185 Positive Marine Style Battery Lug 1
085186 Negative Marine Style Battery Lug 1
