Finn Bark Blower BB302 - Control Panel and Control Systems

BB302 MU2018 Rev B
77
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
CONTROL PANEL AND CONTROL SYSTEMS
Ref. Kit
No. Ref. Part Number Description No. Req’d
1  031520 Controller/Display, Yanmar T4F 1
2  055841 BB302 Control Box Decal (2014 Yanmar) 1
3  055828-01 Box, Modified 1
4  055851 Ignition Switch, 2 Position 1
 031506-01 Ignition Switch Key 1
5  080526 Toggle Switch Boot 1
6  075735-06 Deutsch Receptacle 1
7  052112 Toggle Switch 1
8  075858-KP Key Pad, Cervis Control System 1
9  075858-M Module, Key Pad, Cervice Control System 1
10  055828-02 Sub Panel, Modified 1
11  031575 Mini ATM Fuse block, 4 Position with Clear Cover 1
12  031578 Micro ISO Relay, 12V, SPDT, 35A NO, 25A NC, Sealed 1
13  055883 Throttle Hook-up Conveter (RTS) 1
14  075906 Nylon Standoff W/8-32 Thread 4
15  075858-RP Remote Start/Stop Pendant 1
16  075858-T Radio Remote Transmitter 1
NOT SHOWN
 031577 Mini ATM Fuse, 20A (Yellow) 2
 031576 Mini ATM Fuse, 15A (Blue) 1
 055839 Control Box Wiring Harness 1
055836-02 Battery Ground Cable 1
055836-03 Starter Cable Assembly 1
055836-04 Frame Ground Cable Assembly 1
055836-01 Engine Harness 1
055840 Hydraulic Harness 1
002256-12 Battery, 12V 1
 055867 Coaxial Antenna Cable (15 in.) 1
 075736-A Control Box Coaxial Antenna 1
KITS AND MARKERS
 055884 Complete Control Box Assembly
 075858 BB302 Control System Kit
