WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
AIR LOCK PARTS
Ref. Kit
No. Ref. Part Number Description No. Req’d
NOT SHOWN
Air Lock Inlet End Plate Hardware
----------- 7/16-14 X 2 in. Long Hex Head Cap Screw 4 per
----------- 7/16-14 X 1-3/4 in. Long Hex Head Cap Screw 4 per
----------- 7/16 Flat Washer 8 per
----------- 7/16 Lock Washer 4 per
----------- 7/16-14 Hex Nut 4 per
Air Lock Outlet Plate Hardware
----------- 7/16-14 X 2 in. Long Hex Head Cap Screw 4 per
----------- 7/16-14 X 1-3/4 in. Long Hex Head Cap Screw 4 per
----------- 7/16 Flat Washer 8 per
----------- 7/16 Lock Washer 4 per
----------- 7/16-14 Hex Nut 4 per
Discharge Insert Hardware 1 per
----------- 1/4-20 X 3/4 in. Long Socket Flat Head Cap Screw 4 per
Rotor Shaft Bearing Hardware 1 per
----------- 7/16-14 X 1-1/2 in. Long Hex Head Cap Screw 4 per
----------- 7/16 in. Lock Washer 4 per
055517 Motor Gasket 1 per
055464-1B Gearbox Lip Seal 1 per
----------- 5/16-18 X 3/4 in. Long Set Screw ** 2 per
055463 Hex Plug 2 per
055402 3/8 in. Hardened Rotor Key 1 per
XS0444 1/4-20 X 2 in. Square Head Set Screw 4 per
----------- 1/4-20 Hex Nut 4
055623-02 Deflector Skirt 2
055332 Expansion Plug 1
KITS AND MARKERS
055656 Air Lock Assembly
* Hardware Installed Using Red Loctite
®
** Hardware Installed Using Blue Loctite
®
