MS-9600LS Series Manual — P/N 52646:B8 11/20/2015 79
Master Programming Level Programming
Monitor Type Action When Activated
Pull-Station Fire Alarm
User-Defined-1 same as previous (Pull-Station)
Waterflow Fire Alarm Delayed
User-Defined-2 same as previous (Waterflow)
Monitor Fire Alarm
User-Defined-3 same as previous (Monitor)
Future not used
Future not used
Smoke-Conventional
1
1 Conventional 2-wire smoke detectors may be powered using an external power supply with an
SLC Control Relay Module programmed for Resettable Power operation (refer to note 1 on
page page 84).
Fire Alarm
User-Defined-5 same as previous (Smoke-Conventional)
Heat-Conventional Fire Alarm
User-Defined-6 same as previous (Heat-Detector)
Medic-Alert
2
2 Combination systems employing these non-fire monitor types require the SLC loop to be
programmed by the installer for Style 4 operation and isolator modules must be employed on
each non-fire branch of the SLC as per Figure 13 in the Fire-Lite SLC Wiring Manual # 51309.
Fire and non-fire devices must not be used on the same SLC branch.
Supervisory, latching
User-Defined-7 same as previous (Medic-Alert)
Hazard-Alert
2
Supervisory, latching
User-Defined-8 same as previous (Hazard-Alert)
Tornado-Alert
2
Supervisory, latching
User-Defined-9 same as previous (Tornado-Alert)
Phone Active Phone (LCD display only)
User-Defined-10 same as previous (Phone)
Tamper Supervisory, nonlatching (tracking)
User-Defined-11 same as previous (Tamper)
Supervisory Supervisory, latching
User-Defined-12 same as previous (Supervisory)
Supervisory-AR
3
3 For all entries ending in AR, AR refers to AutoResettable.
Supervisory, nonlatching (tracking)
User-Defined-13 same as previous (Supervisory-AR)
HVAC OVRRIDE
4
4 For HVAC RESTART and HVAC OVRRIDE descriptions, refer to “Monitor Module Operation”
on page 170.
Switch Supervisory, nonlatching (tracking)
Power-Monitor Power Fault
User-Defined-14 same as previous (Power Monitor)
Trouble-Monitor Trouble
User-Defined-15 same as previous (Trouble Monitor)
Process-Monitor
2
Piezo
User-Defined 16 same as previous (Process-Monitor)
Process-Monitor-AR
2, 3
Piezo, nonlatching (tracking)
User-Defined-17 same as previous (Process-Monitor-AR)
MNS Event Allows the Mass Notification System to override FACP programming and turn off
designated active outputs
Future not used
Future not used
Ack-Switch Acts like panel Acknowledge Key
Sil-Switch Acts like panel Silence Key
Reset-Switch Acts like panel Reset Key
Drill-Switch Acts like panel Drill Key
PAS-Bypass PAS Disable
HVAC RESTART
4
Switch
Drill-Switch-AR
3
Drill Switch, nonlatching (tracking)
Table 3.1 Monitor Types
