FIRETRACE FK-5-1-12 - Cylinder Mounting Bracket (100003, 100006, 111206, 111020); Figure 1 - Unit Assembly; Table 3 - Unit Assembly Dimensions

800027-A 4 06/05/2023
Figure 1 – Unit Assembly
Unit Assembly
Part Number
Cylinder Part
No.
Agent
Dimension "A"
Dimension "B"
Dimension "C"
lb
kg
in
cm
in
cm
in
cm
940205
100300
2.5
1.13
15.7
39.8
13.2
33.5
2.9
7.4
940555
100600
5
2.27
16.7
42.3
13.6
34.6
4.3
10.9
941055
101200
10
4.54
16.9
42.9
13.8
35.1
6.4
16.2
942055
120020
20
9.07
24.6
62.5
21.1
53.6
8.4
21.3
Table 3 – Unit Assembly Dimensions
3.1 Cylinder Mounting Bracket (100003, 100006, 111206, 111020)
The cylinder mounting brackets are manufactured from steel with a primed and powder coated paint finish. Each cylinder mounting bracket is
designed to fit properly around the cylinder. The cylinder mounting bracket is equipped with finger tabs which allow easy access. The cylinder
mounting bracket must be secured to a surface appropriate for retaining the weight of the cylinder in the event of a discharge. This precaution is
intended to safely support the weight of the cylinder and the reaction force of the FK-5-1-12 discharge.
All cylinders must be mounted vertically only, with the valve on top. Please refer to Figure 2 – Cylinder Mounting Bracket Bolt Pattern, Table 4 –
940205 Cylinder Mounting Bracket Dimensions, Table 5 – 940555 Cylinder Mounting Bracket Dimensions, Table 6 – 941055 Cylinder Mounting
Bracket Dimensions and Table 7 – 942055 Cylinder Mounting Bracket Dimensions for cylinder mounting bracket dimensions.
