800027-A 7 06/05/2023

Table 8 - Firetrace Detection Tubing Properties

Hydrostatic Burst

Pressure

Minimum Burst Pressure

1100 psi [75 bar]

Typical Burst Pressure

1300 psi [88 bar]

Electrical Properties

Volume Resistivity

1014 (per DIN 53481)

Dielectric Strength

40k V/mm (per DIN 53481)

Table 9 – Firetrace Detection Tube Part Numbers

Firetrace Detection

Tubing Part Number

Description

200005

Firetrace Detection Tubing, 4/6 mm, 1 ft

204025

Firetrace Detection Tubing, 4/6 mm, 25 ft

204050

Firetrace Detection Tubing, 4/6 mm, 50 ft

204100

Firetrace Detection Tubing, 4/6 mm, 100 ft

204328

Firetrace Detection Tubing, 4/6 mm, 328 ft
