Class C Fires (Waysmos FK-5-1-12)
Table 66 – Class C Fire Enclosure Volume Limitations for 940205 Unit Assembly
Design Temperature
Maximum Enclosure Volume
Concentration
°F
°C
ft³
m³
%
0
-17.8
47.9
1.36
4.890
10
-12.2
49.1
1.39
20
-6.7
50.3
1.42
30
-1.1
51.5
1.46
40
4.4
52.7
1.49
50
10.0
53.9
1.53
60
15.5
55.0
1.56
70
21.1
56.2
1.59
80
26.7
57.4
1.63
90
32.2
58.6
1.66
100
37.8
59.8
1.69
110
43.3
61.0
1.73
120
48.9
62.2
1.76
130
54.4
63.4
1.79
Table 67 – Class C Fire Enclosure Volume Limitations for 940555 Unit Assembly
Design Temperature
Maximum Enclosure Volume
Concentration
°F
°C
ft³
m³
%
0
-17.8
95.8
2.71
4.890
10
-12.2
98.2
2.78
20
-6.7
100.6
2.85
30
-1.1
103.0
2.92
40
4.4
105.3
2.98
50
10.0
107.7
3.05
60
15.5
110.1
3.12
70
21.1
112.5
3.18
80
26.7
114.8
3.25
90
32.2
117.2
3.32
100
37.8
119.6
3.39
110
43.3
122.0
3.45
120
48.9
124.3
3.52
130
54.4
126.7
3.59
