Class C Fires (3M™ Novec™ 1230, Noah NY5112 & Dukare 1230)
Table 62 – Class C Fire Enclosure Volume Limitations for 940205 Unit Assembly
Design Temperature
Maximum Enclosure Volume
Concentration
°F
°C
ft³
m³
%
0
-17.8
50.3
1.43
4.667
10
-12.2
51.6
1.46
20
-6.7
52.8
1.50
30
-1.1
54.1
1.53
40
4.4
55.3
1.57
50
10.0
56.6
1.60
60
15.5
57.8
1.64
70
21.1
59.1
1.67
80
26.7
60.3
1.71
90
32.2
61.6
1.74
100
37.8
62.8
1.78
110
43.3
64.0
1.81
120
48.9
65.3
1.85
130
54.4
66.5
1.88
Table 63 – Class C Fire Enclosure Volume Limitations for 940555 Unit Assembly
Design Temperature
Maximum Enclosure Volume
Concentration
°F
°C
ft³
m³
%
0
-17.8
100.7
2.85
4.667
10
-12.2
103.2
2.92
20
-6.7
105.7
2.99
30
-1.1
108.1
3.06
40
4.4
110.6
3.13
50
10.0
113.1
3.20
60
15.5
115.6
3.27
70
21.1
118.1
3.34
80
26.7
120.6
3.42
90
32.2
123.1
3.49
100
37.8
125.6
3.56
110
43.3
128.1
3.63
120
48.9
130.6
3.70
130
54.4
133.1
3.77
