FIRETRACE FK-5-1-12 - Table 72 - Class C Fire Enclosure Volume Limitations for 941055 Unit Assembly; Table 73 - Class C Fire Enclosure Volume Limitations for 942055 Unit Assembly

800027-A 55 06/05/2023
Table 72 – Class C Fire Enclosure Volume Limitations for 941055 Unit Assembly
Design Temperature
Maximum Enclosure Volume
Concentration
°F
°C
ft³
m³
%
0
-17.8
178.8
5.06
5.225
10
-12.2
183.2
5.19
20
-6.7
187.6
5.31
30
-1.1
192.1
5.44
40
4.4
196.5
5.56
50
10.0
200.9
5.69
60
15.5
205.3
5.81
70
21.1
209.8
5.94
80
26.7
214.2
6.07
90
32.2
218.6
6.19
100
37.8
223.1
6.32
110
43.3
227.5
6.44
120
48.9
231.9
6.57
130
54.4
236.3
6.69
Table 73 – Class C Fire Enclosure Volume Limitations for 942055 Unit Assembly
Design Temperature
Maximum Enclosure Volume
Concentration
°F
°C
ft³
m³
%
0
-17.8
357.6
10.12
5.225
10
-12.2
366.4
10.38
20
-6.7
375.3
10.63
30
-1.1
384.1
10.88
40
4.4
393.0
11.13
50
10.0
401.8
11.38
60
15.5
410.7
11.63
70
21.1
419.5
11.88
80
26.7
428.4
12.13
90
32.2
437.2
12.38
100
37.8
446.1
12.63
110
43.3
455.0
12.88
120
48.9
463.8
13.13
130
54.4
472.7
13.38
