FIRETRACE FK-5-1-12 - Table 58 - Class B Fire Enclosure Volume Limitations for 940205 Unit Assembly; Table 59 - Class B Fire Enclosure Volume Limitations for 940555 Unit Assembly

800027-A 48 06/05/2023
Table 58 – Class B Fire Enclosure Volume Limitations for 940205 Unit Assembly
Design Temperature
Maximum Enclosure Volume
Concentration
°F
°C
ft³
m³
%
0
-17.8
38.3
1.09
6.04
10
-12.2
39.3
1.11
20
-6.7
40.2
1.14
30
-1.1
41.2
1.17
40
4.4
42.1
1.19
50
10.0
43.1
1.22
60
15.5
44.0
1.25
70
21.1
45.0
1.27
80
26.7
45.9
1.30
90
32.2
46.9
1.33
100
37.8
47.8
1.35
110
43.3
48.8
1.38
120
48.9
49.7
1.41
130
54.4
50.7
1.43
Table 59 – Class B Fire Enclosure Volume Limitations for 940555 Unit Assembly
Design Temperature
Maximum Enclosure Volume
Concentration
°F
°C
ft³
m³
%
0
-17.8
76.7
2.17
6.04
10
-12.2
78.6
2.22
20
-6.7
80.5
2.28
30
-1.1
82.4
2.33
40
4.4
84.3
2.39
50
10.0
86.2
2.44
60
15.5
88.1
2.49
70
21.1
90.0
2.55
80
26.7
91.9
2.60
90
32.2
93.7
2.65
100
37.8
95.6
2.71
110
43.3
97.5
2.76
120
48.9
99.4
2.82
130
54.4
101.3
2.87
