FISCHBEINCOMPANY
The Leader in Bag Closing Technology
REF : 14810F-GB
ED.A10/2001
32
PLATE A : HOUSING - NEEDLE , LEVER - PRESSER FOOT .
PARTS LIST .
Item . Qty . Part number Description :
1 1 11448 Housing assembly
5 SS 832316HD Screw , bushings Soc , set # 8-32 x3/16
2 6 SC83212 Screw # 8-32 x 5/8
3 1 40004 Name plate
4 2 11010 Stud , feed dog , carrier slide .
5 4 SB 103214 Soc button screw # 10-32 x1/4
6 1 11102 Cover , looper
7 1 11108 Stud looper cover
8 3 F 64038 Flat sunk screw # 6-40 x 3/8
9 1 11210 Throat plate
12 1 11101 Guard needle bar .
12.1 1 11104 Guard needle bar , add.
13 4 B 83214 Binding screw # 8-32 x 1/4
14 1 11009 Plate , cover
16 1 11657 Cover slide pad
17 1 11656 Pad , slide
18 1 11651 Plate lever
19 2 PH 832516 Phillips Head Screw # 8-32 x 5/16
20 1 11654 Lever lifter , presser foot
21 2 11655 Washer spring
22 1 11653 Screw , pivot
23 1 11400 Assy. presser foot
1 11402 Bolt , hinging
1 11711 Nut
2 SS 832316HD Screw , bushings Soc , set # 8-32 x3/16
23.1 1 11883 Guide , needle presser foot
2 B 540316 Binding screw # 5-40 x 3/16
23.2 1 11882 Guard needle
24 1 11444 Bushing , lower
25 1 11652 Lifter presser foot
1 SC 64058 Soc. cap screw # 6-40 x 5/8
26 1 11414 Spring presser bar
27 1 11404 Presser bar
28 2 11442 Bushing , upper presser bar
29 1 13050 Needle D5 , round point
30 1 11501 Nut needle bar
31 1 11443 Bushing needle bar , lower
32 1 11500 Needle bar
33 1 11508 Wicking
34 1 40502 Assy. Clamp needle bar (double)
35 1 11268 Nut , lock (Nylock) 3/8-24NC
36 1 A 3934 Washer flat # Idler
