FISCHBEINCOMPANY
The Leader in Bag Closing Technology
REF : 14810F-GB
ED.A10/2001
33
Item. Qty. Part number. Description .
37 1 40287 Pin pivot
38 2 WT 38132 Washer thrust needle lever
39 1 67694 Ring Retaining E-style ( 3/8” shaft)
40 1 40099 Assy , clamp needle bar and lever
41 1 11510 Spring
42 1 WF 10 Flat washer # 10
43 1 H 103212 Hex screw # 10-32 x 1/2
44 1 11112 Assy , thread tension
45 1 F 64038 Flat sunk screw # 6-40 x 3/8
46 1 11116 Nut , tension - upper
47 1 11117 Nut , tension - lower
48 1 11115 Spring , tension
49 2 11114 Disc , tension
50 1 11113 Stud , tension
51 4 11109 Eyelet , thread pull off
52 1 11120 Washer lock ¼” LT tension
53 1 11025 Lever, Needle
