GuiderⅡ User Guide | www.flashforge.com
e. Make Cur r ent Position Zero button: Set the current position of the
extruder/build plate as (0, 0, 0). (NOTE: X, Y, and Z boxes are for display purposes.
Changing the value in the boxes will not affect anything.
f. Center X/Y/Z button: Extruder and build platform will back to the zero (0, 0, 0)
g. X/Y Speed and Z Speed: Set the move speed of extruder/ build platform.
● Limit Switch: In order to protect your GuiderⅡ, three limit switches are equipped
to control the maximum position, and the three limit switches corresponding to X/Y/Z
axis limit switch. It has two statuses:
a. Not Tr igger ed: If the extruder/build plate don’t move to its maximum, X/Y/Z axis
limit switch is not triggered, and shows “Not Triggered”.
b. Trigger ed: If the extruder/build plate moves to its maximum, X/Y/Z axis limit
switch is triggered, and shows “Triggered”.
● Stepper Motor Contr ols: Allows users to control to stepper motor. Click [Enable],
and lock the motor so it does not allow any movement; click [Disable], and unlock the
motor to be controlled manually.
● LED Color : Allow users to change the LED color of GuiderⅡ.
● Extr uder Contr ols: You can set the value of “Motor Speed (RPM)”, which can
control the rotation speed of filament feeding wheel. The motor rotation time can be
controlled via setting the value of “Extr uder Dur ation”. Generally we suggest the
users choose option of continuous time 60 seconds. The filament must be loaded in the
extruder before motor starts. Therefor e, do not star t r otation oper ation until the
extr uder temper ature r eaches to the printing temper ature of filament. For PLA
filament, the extruder temperature should reach 200℃, after reaching the extruder
temperature, click the [For war d]/[Reverse] rotation button to control filament load
