Page 15
Programming a Day of the Week Regenerated System
1. Extended Programming Mode
Regeneration Cycle Step Programming (Display Code 1 – 6)
Use this feature to program the Regeneration Cycle step times. The Regeneration Cycle Step being
programmed appears in the rst digit of the display. Each display is used to set the duration time in minutes
of that specic step in the regeneration cycle.
Example:
Cycle Step dF dFFF FLtr
1 10 = Backwash 12 = Fill 10 = Backwash
2 60 = Brine Draw 60 = Brine Making 10 = Rapid Rinse
3 5 = 2nd Backwash 10 = Backwash
10 = Rapid Rinse 60 = Brine Draw
5 12 = Rell 5 = 2nd Backwash
6 10 = Rapid Rinse
— Use the Set Up and Set Down buttons to adjust this value.
— Press the Extra Cycle button once to proceed to the next step.
— Set to 1 or 0 using the Set Up and Set Down buttons (1 enables a regeneration for that day; 0 disables
a regeneration for that day).
— Press the Extra Cycle button once to exit Setup Programming mode.
