Fleck 7000 - Inserting Circuit Board; Circuit Board Installation Guide

Page 29
Inserting Circuit Board
1. To insert the circuit board, align the notches on the left side of the board with the exible nger on the power
head. Apply pressure to the left while rotating the board back.
2. When all the way down, snap the circuit board into place under the notches on the right.
