FLENDER N-EUPEX - Type BDS; Figure A-2 Type B; Figure A-4 Type BDS; A.1.4 Type BDS

Size Speed
n
max.
rpm
Maximum bore
1)
DA
mm
ND1
mm
ND2
mm
NL1 / NL2
mm
S
mm
U1
mm
U2
mm
P
mm
Weight
2)
m
kg
D1
mm
D2
mm
514 1 400 180 145
180
514 300 240
300
190 5 … 10 90 65 104 220
237
556 1 300 190 150
190
556 315 250
315
210 5 … 10 102 68 115 281
290
1)
Maximum bore for parallel keyway in accordance with DIN 6885/1.
2)
Weight applies to one coupling with maximum bore.
A.1.4 Type BDS

8
8
1/1/
'
1'
'$
'
1'
6
1 Coupling part 1
4 Coupling part 4
Figure A-4 Type BDS
Table A-4 Speeds, geometry data and weights of type BDS
Size Speed
n
max.
rpm
Maximum bore
1)
DA
mm
ND1
mm
ND2
mm
NL1 / NL2
mm
S
mm
U1
mm
U2
mm
Weight
2)
m
kg
D1
mm
D2
mm
66 7 500 19 24 66 66 40 20 2 … 4 20 8 0.5
76 7 000 24 28 76 76 50 20 2 … 4 20 8 0.65
88 6 000 30 38 88 88 68 30 2 … 4 30 10 1.8
103 5 500 42 42 103 76 76 35 2 … 4 30 12 3
118 5 300 48 48 118 86 86 40 2 … 4 34 14 3.7
135 5 100 55 55 135 100 100 50 2 … 4 36 18 6.1
152 4 900 60 60 152 108 100 55 2 … 4 36 20 7
172 4 250 65 65 172 118 108 60 2 … 6 41 20 11
194 3 800 75 75 194 135 125 70 2 … 6 44 20 17
Technical data
A.1 Speeds, geometry data and weights
