You can calculate the numerical values in the table and their intermediate values as follows:
ΔKr
perm
= ΔS
perm
= (0.1 + DA / 1000) · 40 / √n Coupling speed n in rpm
DA in mm (see Speeds, geometry data and
weights (Page 57))
Radial misalignment ΔKr
perm
in mm
The values in column "250 rpm" of the table above apply for speeds of < 250 rpm.
A.3 Tightening torques and widths A/F
Table A-6 Tightening torques for part 13 of types A and ADS
N‑EUPEX-
Coupling
N‑EUPEX DS-
Coupling
Tightening torque T
A
and width A/F SW for
Hexagon socket-head screws according to DIN EN ISO 4762
Size
Size T
A
Nm
SW
mm
110 118 14 6
125 135 17.5 6
140 152 29 8
160 172 35 8
180 194 44 8
200 218 67.5 10
225 245 86 10
250 272 145 14
280 305 185 14
315 340 200 14
350 380 260 17
400 430 340 17
440 472 410 17
480 514 550 19
520 556 670 19
560 - 710 19
610 - 1 450 22
660 - 1 450 22
710 - 1 450 22
Apply the recommended tightening torques in accordance with the stipulations in section
Tightening procedure (Page 64).
Technical data
A.3 Tightening torques and widths A/F
N-EUPEX / N-EUPEX DS 3100en
Operating Instructions 10/2017 63
