FOM16 Installation Description
FOM16-V2.0-20021114
-10-
6. Front Panel Operation
The front panel consists of a two by twenty (2x20) characters LCD display window and four
keypads each labeled with ESC, Enter, Up, Down, as shown in Fig13.
Enter key is used to move down the menu tree or to enable a selection.
Up and Down keys show other menu item in the same level.
ESC key returns the operation to an upper layer menu or to the main menu.
The first line of LCD shows the operation items and selected items are underlines by a “_” in the
first character.
The second line displays a help string.
A “<” or a ”>” represent the menu is a multi-page.
