FlexGain FOM16 - Line Equalizer Setting Menu

FOM16 Installation Description
FOM16-V2.0-20021114
-15-
6.2.3 Line Equalizer Setting Menu( T1 TYPE ONLY)
PATH: CONFIGUREÆEQU
1. Use the ◄ key and ► key to cycle through to a proper channel and press the Enter key to
select the module.
2. Use the ◄ key and ► key to cycle through to a proper channel and press the Enter key to
select the channel.
3. Use ◄ and ► key to cycle through to a proper equalization type and press Enter to select.
4. When completed , the bottom line shows “ -- -- OK -- -- “ message.
NOTE: If card type is E1 , it shows message
SVC CODE EQU
>
ALL 1 2 3 4 5 6
>
0 1 2 3 4
T1 : 0 – 133 ft.
0 1 2 3 4
-- -- OK -- --
0 1 2 3 4
E1 Can’t set EQ!
