FlexGain FOM16 - Reset Menu; Loopback Setting Menu

FOM16 Installation Description
FOM16-V2.0-20021114
-17-
6.2.5 Reset Menu
PATH: CONFIGUREÆ RESET
1. Use the ◄ key and ► key to cycle through to a proper channel and press the Enter key to
select the function.
2. Use the ◄ key and ► key to cycle through to a proper channel and press the Enter key to
select the option.
3. When completed , the bottom line shows “ -- -- OK -- -- “ message.
6.2.6 Loopback Setting Menu
PATH: CONFIGUREÆLPBKÆLS
1. Use the ◄ key and ► key to cycle through to a proper channel and press the Enter key to
select the module.
2. Use the ◄ key and ► key to cycle through to a proper channel and press the Enter key to
select the channel.
3. Use the ◄ and ► key to cycle through to a proper loopback type and press Enter to select.
LPBK RLSLPBK PROTSW <
Set-LPBK
LS OPT
Low-Speed
ALL 1 2 3 4 5 6 >
Channel 1
LOCAL REMOTE
Local loopback
LOCAL REMOTE
Remote loopback
ADDRESS RESET >
Reset FOM16
NO YES
NO
NO YES
-- -- OK -- --
NO YES
YES
