FLUXUS G80x 3 General Principles
16 UMFLUXUS_G8V4-6-1EN, 2018-10-10
3.3.2 Examples
diagonal arrangement with 1 beam reflection arrangement with 1 beam
1 transducer pair
1 sound path
1 beam
1 plane
1 transducer pair
2 sound paths
1 beam
1 plane
diagonal arrangement with 2 beam reflection arrangement with 2 beams and 2 planes
2 transducer pairs
1 sound path
2 beams
1 plane
2 transducer pairs
2 sound paths
2 beams
2 planes
X arrangement
displaced
X arrangement
