12 Displaying the Measured Values FLUXUS G80x
UMFLUXUS_G8V4-6-1EN, 2018-10-10 85
The following list items are available:
If a totalizer is activated during the measurement of the standard volumetric flow rate, the standard volumetric flow rate will
be totalized. The unit of measurement of the standard volume will be displayed without a prefix.
12.2 Toggling between the Channels
If more than one channel is available/activated, the display for the measured values can be adapted as follows:
• AutoMux mode
– all channels
– only calculation channels
• HumanMux mode
The command →Mux:Auto/Human toggles between the modes (see section 13.1).
12.2.1 AutoMux Mode
In the AutoMux mode, the display and the measuring process are synchronized. The channel on which a measurement is
being made is displayed in the upper line on the left.
The measured values are displayed as configured in the program branch Output Options (see section 12.1). When the
multiplexer switches to the next channel, the display is updated.
The default is the AutoMux mode. The AutoMux mode will be activated after an initialization of the transmitter.
All Channels
The measured values of all channels (measuring and calculation channels) are displayed. The next active channel is se-
lected after min. 1.5 s.
Only Calculation Channels
Only the measured values of the calculation channels are displayed. The next active calculation channel is displayed after
min. 1.5 s.
This mode can only be activated if at least 2 calculation channels are active.
12.2.2 HumanMux Mode
In the HumanMux mode, the measured values of one channel are displayed. The measurement on the other channels is
continued, but not displayed.
Select the command →Mux:Nextchan. to display the next activated channel. The measured values of the selected
channel will be displayed as configured in the program branch Output Options (see section 12.1).
list item display of the operating volumetric flow
rate
display of the standard volumetric
flow rate
(none) without prefix, e.g., m³/h without prefix, e.g., m³/h
’ ’/’N’ without prefix, e.g., m³/h with prefix N, e.g., Nm³/h
’ ’/’S’ without prefix, e.g., m³/h with prefix S, e.g., Sm³/h
’A’/’S’ with prefix A, e.g., Am³/h with prefix S, e.g., Sm³/h
The selected channel is displayed left in the upper line.
A:
act. Volume flow
54.5 m3/h
