FLUXUS G80x 12 Displaying the Measured Values
86 UMFLUXUS_G8V4-6-1EN, 2018-10-10
12.3 Adjustment of the Display
During the measurement, the display can be adapted as to display two measured values simultaneously (one in each line
of the display). This does not affect totalizing, transmission of the measured values, etc.
The following information can be displayed in the upper line:
The measured values of the physical quantity selected in the program branch Output Options can be displayed in the
lower line:
Press key during the measurement to change the display in the upper line, press key to change the display in
the lower line.
12.4 Status Line
Important data of the ongoing measurement are shown in the status line. The quality and precision of the ongoing mea-
surement can be estimated.
display explanation
Mass Flow= designation of the physical quantity
A: +8.879 m3 values of the totalizers
full= date and time at which the data logger will be full, if activated
Mode= measuring mode
L= transducer distance
Compress= gas compressibility coefficient
Rx= alarm state indication, if activated (see section 18.7.5) and if alarm outputs are activated (see section
18.6).
status line (see section 12.4)
display explanation
12.3 m/s flow velocity
1423 m/s sound speed
124 kg/h mass flow rate
15 m3/h standard volumetric flow rate or operating volumetric flow rate
The character * indicates that the displayed value (here: flow velocity) is not the selected
physical quantity.
Press key during the measurement to scroll through the upper line to the status line.
A:Flow Velocity
* 2.47 m/s
To Next Page
