FT-112(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 105 of 170
Entry the limit values at basic weighing
1. Press the key.
2. The setpoint 1 value appears as shown on the display [ SP 1 1250 kg ].
3. Enter the new value by numerical keys. You may press key to enter negative limit value. Press
the key to save it and to go to the next setpoint.
4. Repeat from step 2 for entering following setpoints.
5. The indicator returns to the operation after displaying setpoint 5 and entering its value,
6. Press key to return operation at any step.
Entry setpoint of items into SET memory
1. Press key for more than 2 seconds. [ MEMORY ] prompt appears.
2. Press key. The last used Set memory group number appears as [ SET : 111 ].
3. Enter the new memory code by pressing the numerical keys and press key to enter the item.
4. The first limit value will appear on the display as [ SET 111 - SP1 ] [ 10.00 kg ]. Enter the new
value by numerical keys and press the key.
5. The following limit value appears as [ SET 111 - SP2 ] [ 20.00 kg ]. Enter new value by numerical
keys and press the key.
6. Repeat step 4 and 5 until entering values to other three limit value of the group.
7. After entering the value of 5th setpoint value press key to check values again.
8. Or press key to increase the memory code.
9. Or press key to decrease the memory code.
10. Or press key to exit.
Select limits of item from SET memory
1. Press key. The last used setpoint value appears on the display as [ SP1 1250 kg ].
2. Press key. The last used Set memory code appears on the display [ SET : 111 ].
3. Enter the memory code of the item by pressing the numerical keys and press key.
4. The selected Set memory data is loaded after displaying values.
5. Or press key to exit without loaded.
Limit values at SmartAPP
Digital inputs and outputs are set to their application related functions automatically if any SmartAPP operation
is programmed. The non-used inputs and outputs of the selected SmartAPP application can be programmed
to the any function described above.
For example, the Output 5 of the Filling is not used by the Filling application software and it can be used as
zero range output to check the scale unloading.
Refer to SmartAPP section 11.2, page 94, for usage of digital inputs and outputs details.
